Specification
· Insulation class:B
· Protection class:IP68
· Water temperature:up to 40 ℃
· PH:6 to 10
· Density of liquid:1.3g/cm
· Power supply:three phase 380V±10%,50Hz three phase 380V±10%,60Hz single phase 220V±10%,50Hz single phase 220V±10%,60Hz
· Motor protection:built in
· Capacity:up to 5500 m³/h
● Head:up to 100m
· Maximum immersion depth:10m
· Cable length:8m
Model | Rated Flow Rate (m³Lh) | Rated Head (m) | Power (kw) | Voltage (V) | Datate Speed (r/min) | Outlet dia. (in) |
25WQ5-20-0.75 | 5 | 20 | 0.75 | 380 | 2900 | 1 |
32WQ6-18-0.75 | 6 | 18 | 0.75 | 380 | 2900 | 1.2 |
40WQ7-15-0.75 | 7 | 15 | 0.75 | 380 | 2900 | 1.5 |
50WQ10-10-0.75 | 10 | 10 | 0.75 | 380 | 2900 | 2 |
65WQ15-7-0.75 | 15 | 7 | 0.75 | 380 | 2900 | 2.5 |
25WQ5-22-1.1 | 5 | 22 | 1.1 | 380 | 2900 | 1 |
32WQ6-20-1.1 | 6 | 20 | 1.1 | 380 | 2900 | 1.2 |
40WQ7-18-1.1 | 7 | 18 | 1.1 | 380 | 2900 | 1.5 |
50WQ10-12-1.1 | 10 | 12 | 1.1 | 380 | 2900 | 2 |
65WQ15-9-1.1 | 15 | 9 | 1.1 | 380 | 2900 | 2.5 |
50WQ10-16-1.5 | 10 | 16 | 1.5 | 380 | 2900 | 2 |
65WQ20-10-1.5 | 20 | 10 | 1.5 | 380 | 2900 | 2.5 |
80WQ40-7-1.5 | 40 | 7 | 1.5 | 380 | 2900 | 3 |
100WQ50-5-1.5 | 50 | 5 | 1.5 | 380 | 2900 | 4 |
50WQ9-22-2.2 | 9 | 22 | 2.2 | 380 | 2900 | 2 |
65WQ20-15-2.2 | 20 | 15 | 2.2 | 380 | 2900 | 2.5 |
80WQ40-10-2.2 | 40 | 10 | 2.2 | 380 | 2900 | 3 |
100WQ50-7-2.2 | 50 | 7 | 2.2 | 380 | 2900 | 4 |
50WQ15-25-3 | 15 | 25 | 3 | 380 | 2900 | 2 |
65WQ25-18-3 | 25 | 18 | 3 | 380 | 2900 | 2.5 |
80WQ45-12-3 | 45 | 12 | 3 | 380 | 2900 | 3 |
100WQ60-9-3 | 60 | 9 | 3 | 380 | 2900 | 4 |
50WQ15-30-4 | 15 | 30 | 4 | 380 | 2900 | 2 |
65WQ25-25-4 | 25 | 25 | 4 | 380 | 2900 | 2.5 |
80WQ40-16-4 | 40 | 16 | 4 | 380 | 2900 | 3 |
100WQ60-12-4 | 60 | 12 | 4 | 380 | 2900 | 4 |
50WQ15-40-5.5 | 15 | 40 | 5.5 | 380 | 2900 | 2 |
65WQ25-30-5.5 | 25 | 30 | 5.5 | 380 | 2900 | 2.5 |
80WQ40-22-5.5 | 40 | 22 | 5.5 | 380 | 2900 | 3 |
100WQ60-18-5.5 | 60 | 18 | 5.5 | 380 | 2900 | 4 |
